TE 7 Rotary hammer

Name: TE 7 Rotary hammer
Brand: Hilti
SKU: r4695

Compact and light-weight D-grip SDS Plus (TE-C) rotary hammer

Customers also searched for hammer drilling, drilling concrete, drilling masonry, drilling or tools & equipment.

Technical Data

Weight according to EPTA-Procedure 01/2003 without battery

2.9 kg

Optimum hammer drilling range

4 - 12 mm

Single impact energy

1.8 J

Working mode

Hammer drilling, Drilling

Hammer drilling diameter range

4 - 24 mm

Hammer drilling RPM

1050 rpm

Full hammering frequency

4980 impacts/minute

Functionality

Integrated Dust Removal System (DRS), Removable chuck, Reverse mode, Depth gauge

Triaxial vibration value for hammer drilling into concrete (ah,HD)

11 m/s² ¹

Triaxial vibration for chiselling in concrete

11 m/s² ²

A-weighted emission sound pressure level

92 dB (A) ³

Dimensions (LxWxH)

320 x 75 x 215 mm

According to the applicable product standard (see the Operating Instruction for more details)
According to the applicable product standard (see the Operating Instruction for more details)
According to the applicable product standard (see Operating Instruction for more details)

Two-mode SDS Plus (TE-C) rotary hammer – for hammer drilling and rotary-only drilling
Ergonomically designed D-grip for comfortable use over long periods
Excellent performance-to-weight ratio and compact design
Virtually dustless drilling when used with the DRS-M dust removal system
Quick-change TE-C Click chuck for versatility and ease of use

Drilling and hammer drilling in concrete and masonry
Occasional drilling in wood and steel with optional quick-release chuck
Drilling in concrete in clean areas using the integrated dust removal system (DRS-M)
Cutting socket recesses in masonry

For approval or certificate information, please see individual items.

3 or free: get the tool serviced and cleaned in 3 days flat or there is no charge
Servicing is free of charge for up to 2 years, including wear and tear, pick-up and delivery
After the no-cost period, repair costs are capped
Product warranty against parts and manufacturing irregularities for as long as we service the tool
Product warranty against parts and manufacturing irregularities for 20 years

No repair costs for 2 years from date of purchase, including parts subject to wear and tear, shipping and labour
After the no-cost period, repair costs are capped for as long as we service the tool
3-month no-repair-cost period again after every paid repair
Materials and workmanship warranty over the entire life of the tool
Pick-up and delivery service
