DST 20-CA 2nd wall saw

Electric wall saw for tough cutting jobs with cut assistance and on-board control electronics (no external e-box)

Pack size

Product options

Quantity

Packs

Total Pieces

You can not see your company prices

Please Log in or register to see your company prices.

Discounted net

Price loading error occured

Please contact us

Technical Data

Motor power

20 kW

Blade diameter - range

600 - 1600 mm

Min. generator power

40 kVA

Power source

Electric

Max. cutting depth

730 mm

Drive weight

32 kg

A-weighted emission sound pressure level

98 dB (A) ¹

Drive dimensions (W x L x H)

1100 x 690 x 1180 mm

Remote control

Wireless

According to the applicable product standard (see Operating Instruction for more details)

Saves you time for other tasks – Hilti cut Assist equips tools for fully automated cutting. Starts when surface is detected, then continuously optimises speed, gear and water flow
Faster cutting time – the Pull/Push mode functionality in cut Assist reduces cutting times compared to the normal pulling mode
Easier assembly and disassembly – the integrated flush cutting flange makes it easier to use
No external e-box necessary – control electronics integrated on-board make the saw more compact, easier to handle and quicker to set up
Cutting depth is displayed in real time on the remote control

Cutting and extending openings in concrete walls and floors
Precise demolition of walls and floors with low vibration
Cutting through heavily reinforced concrete, synthetic and natural stone, brick and block and other mineral-based materials
Cutting in tight spaces and where access is difficult
Facade and balcony renovation

For approval or certificate information, please see individual items.
